sc control system platform introduction
the advanced safety design has greatly improved the stability and reliability of the system.
the advanced safety design has greatly improved the stability and reliability of the system. sc series control system has passed such comprehensive
tests as are strict emc test, high temperature and humidity test, vibration test, and10 thousand hours running test. it has got ce certification from
german professional evaluation agency tuv.
the application of advanced stepping closed loop and all-servo control technology for continuous
technological leading advantages
the advanced stepping closed loop and all servo control technology has been leading the industry. high-performance products of sc series control
system adopt stepping mote with encoder and servo motor, and the vector closed loop motor control technology can realize faster trimming and
presser foot actions and less frame-moving noise. the efficiency is improved by 15%~25% and energy consumption is reduced by more than 20%,
compared with traditional open loop type. in addition, this control system can help traditional machine realize better stitches. now, this series of products
can be applied to all-series machines.
various designs of operation panel to meet needs of various users
various panel designs will satisfy different needs of various users: 10-inch/7-inch/5-inch true color lcd touch panel, lattice lcd and led button panel.
pattern output/input is available via common usb interface. customerization of operation panel is available according to user's special needs.
internationally recognized icons together with english/chinese explanation, with friendly interface, make the panel easy to operate even for new hands.
●features of 10-inch true color lcd touch panel:
|
-a8 processor of stronger performance, memory 2 times bigger, storage space 16
times larger, good multi-task handling performance, and ddr3 memory to make
processing speed 4 times faster;
-10-inch true color lcd with resolution ratio of 800x1280, bigger view area, clearer
display of patterns and changeable background;
-wifi connection function, to support remote upgrade and remote inquiry of machine status information,
together with dh-net intelligent factory system to realize intelligent management;
-built-in multi-media instructions for convenient reference to users' manual and malfunction treatment;
-largest stitch interval of 12.7mm, to improve pattern designing experience for thick fabric sewing machine.
-support various languages: chinese (simplified), chinese (traditional), english, korean, japanese, burmese. turkish, etc. |
 |
●instruction of 7-inch tft lcd touching panel (vertical type/
horizontal type):
-7-inch tft lcd displayer, touching panel, vivid display and simple operation;
-all major cad data formats supprt，also campatibility embroildery data formats;
-support the pattern transfer via u disk and the input with multiple formats; can
store 999 patterns at most;
-have the function for making letter pattern, support 28 kinds of fonts and can
arrange the letters in linear or arc;
-support video and audio displayer; have screen protection function and strong
network extension capability;
-the highlighted management and encryption functions for parameter and machine.
-support various languages: chinese, english, vietnamese, burmese, turkish, etc. |
  |
●instruction of 5-inch tft lcd touching panel (horizontal type):
-the highlighted production control function is easy for user to know the productivity；
-available for the zigzag machine, small size and practical design;
-the sound pattern-designing function enables user to make kinds of complicated patterns；
-high performance platform plus the advanced operation system support the function of handling
several tasks at same time；
-5-inch tft lcd displayer, touching panel, vivid display and simple operation；
-support the pattern transfer via u disk and fast update of software.
-support various languages: chinese, english, korean, etc. |
 |
●lcd panel features:
-classic panel style,the use of easy to understand button icon form;
-has been operating with a good touch button;
-support u disk import pattern,to complete a variety of sewing operations;
-compared with the traditional keys can display text,pattern,contentricher,
more intuitive operation,to meet the different user habits;
-support various languages: chinese, english, etc. |
 |
various styles of control box can be equipped for sc series control system
brand new dahao products of tsc and masc series adopt costomerized "dahao core" and all-digital switch power supply
technology, which comprehensively improves the stability and safety of the products. the application of dhmc design technology
also breakthroughs the traditional design idea, to realize comprehensive integration of main control, display and drive and to
produce the smallest, lightest and most powerful product ever.
|
