features of automatic pattern machine control system:
-the system can be attached with 7-inch honrizontal type,7-inch vertical type tft lcd touching panels.all suppot update of patterns
or programs via usb.
-the system supports the function of human voice guidance. the figures/words combination design on the panelis convenient for use
by different users.apart from easily editing and modifying the patterns,other functions of pausing at midway,parameter encryption,
letter sewing and wifi network extension are also available on the panel;
-the system supports many kinds of mechanical structure, having a super large sewing range: more than 900mm at y direction, not
limited for the roller structure and ±1500mm for other frame structure at x direction.
-
the system supports all kinds of cutting tools, automatic shuttle changing, external laser, lifting head, double shaft drive and other
functions, which demonstrates all the design ideas of complete automation.
-the application of the advanced closed-loop control technology to the stepping motor enables the sewingspeed of 3200sti/min and
the moving speed of 60000mm/min, and supports the speed of 3000rpm when the movement of the presser foot is set at 4mm,
having comprehensively improved the sewing efficiency and product quality.
-the system supports two pattern recognizing methods: with the multi-route sensor and with barcode/figure scanner, which can
greatly improve the productivity compared with the traditional pattern processing method.
-the special pattern-converting software pcs and the special pattern-designing software pds for the pattern machine controller can
support the pattern data in dxf, plt and other formats, and also support the fast inputve of pattern with u-disk, which makes the
pattern update much easier and faster.
-the system supports wifi function by which the user can conduct remote management of patterns and remote maintenance of the
machine,which will greatly improve the production efficiency.
|
asc4xx-mbj computerized control system
for automatic pattern machine |
type: asc4xx-mbj
application: lk-automatic pattern machine |
masc4xx-mbj computerized control system
for automatic pattern machine |
type: masc4xx-mbj
application: lk/plk/bas-automatic pattern machine |
|
|
|
